EDFA-1550H High Power Ytterbium Erbium Doped Fiber Amplifier
2U rack-mountable high power Yb/Er co-doped fiber amplifier with saturated output power up to 40 dBm (10W). Features multi-mode high power pump laser, low noise figure, and optional SNMP network management. Ideal for CATV, FTTH, and long-distance fiber optic transmission systems requiring high output power.
Category: CATV Optical Equipment
Key Features
- High output power – saturated output power from 27 dBm to 40 dBm (500 mW to 10W) with multiple output port options (4–32 ports).
- Low noise figure – optimized pump power distribution for excellent system CNR, noise figure as low as 5.0 dB.
- Reliable design – built-in high-performance switching power supply with 90–265V AC or DC -48V optional; dual fans for automatic temperature control.
- Intelligent monitoring – microprocessor monitors laser status with VFD/LCD display; automatic laser shutdown with alarm for parameter deviations.
- Network management – RJ45 interface for SNMP management (optional).
Technical Specifications
| Parameter | Specification |
|---|---|
| Operating Wavelength | 1540–1560 nm |
| Optical Input Power | -10 to +10 dBm |
| Nominal Optical Input Power | 3 dBm |
| Saturated Output Power | 27–40 dBm |
| Number of Output Ports | 4–32 (customizable) |
| Noise Figure (NF) | 5.0–6.3 dB (@ +0 dBm input, 1550 nm) |
| Optical Output Power Stability | <±0.5 dB |
| Polarization Sensitivity | <0.2 dB |
| Polarization Dependence Gain | <0.4 dB |
| Polarization Mode Dispersion | <0.3 ps |
| Optical Connector (IN/OUT) | SC/APC, FC/APC, or customizable |
| Input/Output Optical Isolation | >30 dB |
| Pump Power Leakage | <-30 dBm |
| Echo Loss | >50 dB |
| SNMP Management Interface | RJ45 (optional) |
| Power Supply | 90–265V AC or DC -48V |
| Power Consumption | <150 W |
| Dimension (WDH) | 19" × 14.5" × 3.5" (482.6 mm × 368.3 mm × 88.9 mm) (2U) |
| Working Temperature | -5°C to 65°C |
| Storage Temperature | -40°C to 80°C |
| Operating Humidity | 5% to 95% |
Specifications and variant information reflect the published catalog. Confirm the exact model, optional features and compatibility with FOT before ordering.
Typical Applications
Ideal for CATV, FTTH, and long-distance fiber optic transmission systems requiring high output power.
